Product Description:
PowerMax™ direct fit performance turbocharger kits are engineered for increased engine performance while maintaining OEM direct fitment. The Garrett PowerMax™ turbocharger upgrade for the 2.0L EA888 Evo4 engine platform. Engineered by enthusiasts, for enthusiasts, this turbocharger upgrade isn’t just about boosting your engine’s capabilities, it’s also about packaging it into your vehicle’s existing OEM setup.
GTX Gen II compressor aerodynamics increase turbocharger flow by a staggering 32% compared to the OEM turbo. Embrace the future of power with the high-temperature Mar-M alloy turbine wheel, paired with state-of-the-art turbine aerodynamics and a robust twin scroll stainless steel turbine housing capable of withstanding up to 1050°C of heat. Elevate your driving game, and experience performance like never before with PowerMax™.
Features:
- Direct-Fit Stage 1 Upgrade
- Complete Assembly With Calibrated Electric Actuator for OE Fitment
- +32% Flow Compared to OEM
- GTX Gen II Compressor Wheel Aero
- Mar-M Alloy Turbine Wheel Material Rated for up to 1050C
- Stainless Steel Turbine Housing Rated for up to 1050C
- Latest Generation of Journal Bearing Rotor Group
- 360-Degree Thrust Bearing – Reinforced for Application
Turbocharger Specifications:
-
Garrett (Factory GTI Turbocharger)
- 6/6 Blade Billet Compressor Wheel & 10 Blade Turbine Wheel
- 41.8 mm Inducer / 57.3 mm Exducer - Compressor
- 39.1 mm Exducer / 44.0 mm Inducer - Turbine
- 26.02 mm Wastegate Flap
- 0.52 A/R
-
Garrett Powermax
- 8 Blade Billet Compressor Wheel & 9 Blade Turbine Wheel
- 47.25 mm Inducer / 60.0 mm Exducer with 62mm Extended Tip - Compressor
- 45.0 mm Exducer / 50.0 mm Inducer - Turbine
- 37.03 mm Wastegate Flap
- 0.65 A/R
Compressor Map:
